Juniper SRX4300 vs SRX1600: Which Next-Gen Firewall Fits Your Network?

The Juniper SRX4300 and SRX1600 are both 1U Junos OS next-generation firewalls with built-in Zero Trust, AI-Predictive Threat Prevention, and EVPN-VXLAN fabric integration. The difference comes down to scale: the SRX4300 is a data center-class engine delivering up to 90 Gbps of firewall throughput with 100GbE QSFP28 ports, while the SRX1600 is right-sized for enterprise campus and edge with 24 Gbps firewall throughput. This comparison breaks down throughput, interfaces, sessions, and the buyer profile each one serves.

Get a quote See the specs

The short answer

Choose the SRX4300 when you are securing a data center edge or core, a high-throughput internet edge, or a service-provider aggregation point that needs 100GbE interfaces and tens of Gbps of inspected NGFW traffic. Choose the SRX1600 for enterprise campus perimeter, regional offices, and mid-size data center segmentation where 24 Gbps firewall and 25GbE uplinks are plenty and budget matters. Both share the same Junos feature set, Mist-managed operations, and AI-Predictive Threat Prevention, so the decision is throughput and interface sizing, not capability. When in doubt, size to peak inspected throughput plus headroom rather than raw firewall numbers.

Juniper SRX4300 vs Juniper SRX1600, head to head

Juniper SRX4300

Juniper SRX1600

Firewall throughput

Up to ~90 Gbps per rack unitadvantage

~24 Gbps

NGFW / IPS inspection

Data center-class, tens of Gbps with FW+AppSec+IPSadvantage

~7.5 Gbps NGFW / ~8 Gbps IPS (IMIX)

Interface speeds

Up to 100GbE (6x QSFP28), 25G/10G/multigigadvantage

Up to 25GbE (SFP28), 10G SFP+, 1GbE RJ45

Concurrent sessions

~10 millionadvantage

~2 million

Connections per second

~800,000advantage

~95,000

Right-sized cost / value

Higher; built for scale

Lower entry point for campus/edgeadvantage

Junos feature parity

Full Junos NGFW, Zero Trust, EVPN-VXLAN, AI threat prevention

Form factor / density

Specifications side by side

Form factor: 1U rack-mountable; 1U rack-mountable
Firewall throughput: Up to ~90 Gbps per rack unit; ~24 Gbps
IPsec VPN throughput: ~94 Gbps (1400B); ~18 Gbps
NGFW throughput (FW + AppSec + IPS): Data center-class (tens of Gbps; datasheet cites up to ~83 Gbps); ~7.5 Gbps (IMIX)
IPS throughput: High (multi-10G class); ~8 Gbps (IMIX)
Max concurrent sessions: ~10 million; ~2 million
Connections per second: ~800,000; ~95,000
100GbE interfaces: 6x QSFP28 (40/100GbE); None
25GbE interfaces: 4x SFP28 (1/10/25G); 2x SFP28 (1/10/25G)
10GbE / multigig ports: 8x SFP+ (1/10G) + 8x 1/2.5/5/10G RJ45; 4x SFP+ (1/10G) + 16x 1GbE RJ45
MACsec: Wire-speed MACsec on ports; Wire-speed MACsec on uplink ports
Power supplies: Redundant (1+1); 1+1 redundant (ships with one; second optional)

Where Juniper SRX4300 wins

Up to ~90 Gbps firewall throughput per RU for data center edge and core
Native 100GbE (QSFP28) plus 25G/10G/multigig flexibility in 1U
~10 million concurrent sessions and ~800,000 connections per second for high-scale workloads
Wire-speed MACsec across high-speed ports for encrypted DC interconnect
Strong NGFW and IPS inspection headroom for north-south data center traffic

Where Juniper SRX1600 wins

Right-sized ~24 Gbps firewall for campus perimeter and enterprise edge at a lower entry cost
16x 1GbE RJ45 plus 25GbE/10GbE SFP uplinks suit mixed campus wiring
Six expansion slots for interface flexibility as needs grow
1+1 redundant power option for branch and regional resilience
Same Junos OS, Zero Trust, EVPN-VXLAN, and AI-Predictive Threat Prevention as larger SRX

Which one should you buy?

Data center edge or core firewall with 100GbE uplinks

Pick Juniper SRX4300. QSFP28 100GbE ports and up to ~90 Gbps firewall throughput handle north-south DC inspection that the SRX1600 cannot reach.

Enterprise campus perimeter and internet edge for a mid-size org

Pick Juniper SRX1600. ~24 Gbps firewall with 25GbE uplinks and 16 copper ports covers typical campus throughput at a lower cost than the SRX4300.

High-session-count internet edge or service-provider aggregation

Pick Juniper SRX4300. ~10 million concurrent sessions and ~800,000 connections per second absorb heavy connection churn and large flow tables.

EVPN-VXLAN data center segmentation at moderate scale

Pick Juniper SRX1600. Both support EVPN-VXLAN fabric integration, and the SRX1600 delivers it economically where 25GbE and 24 Gbps are sufficient.

Regional office or distributed hub needing redundant power and growth headroom

Pick Juniper SRX1600. 1+1 redundant PSUs and six expansion slots give resilience and interface flexibility without paying for DC-class throughput.

Frequently asked

What is the main difference between the SRX4300 and SRX1600?

Scale. The SRX4300 is a data center-class NGFW with up to ~90 Gbps firewall throughput and 100GbE QSFP28 ports, while the SRX1600 is an enterprise campus and edge firewall at ~24 Gbps with up to 25GbE uplinks. Both run the same Junos OS and security features.

How much firewall throughput does each model deliver?

The SRX4300 delivers up to roughly 90 Gbps of firewall throughput per rack unit, with very high IPsec VPN throughput. The SRX1600 delivers about 24 Gbps firewall throughput and around 18 Gbps IPsec VPN throughput.

Do both firewalls support EVPN-VXLAN and Zero Trust?

Yes. Both the SRX4300 and SRX1600 include built-in Zero Trust, EVPN-VXLAN fabric integration, and Juniper AI-Predictive Threat Prevention, so the feature set is consistent across the two platforms.

Which SRX should I pick for a data center versus a campus?

For a data center edge or core that needs 100GbE and tens of Gbps of inspected NGFW traffic, choose the SRX4300. For a campus perimeter, internet edge, or regional office where 24 Gbps and 25GbE uplinks are sufficient, the SRX1600 is the right-sized, lower-cost choice.

Can these firewalls be managed in the cloud?

Both are Junos OS SRX Series firewalls and integrate with Juniper Mist cloud management for the security and SD-WAN portfolio, in addition to traditional Junos CLI and Junos Space management. Confirm the exact management mode for your software release with us before ordering.

How many concurrent sessions does each support?

The SRX4300 supports roughly 10 million concurrent sessions and about 800,000 connections per second, while the SRX1600 supports around 2 million concurrent sessions and about 95,000 connections per second.

Are the SRX4300 and SRX1600 available on TAA, GSA, or SAP/FAR channels contract vehicles?

As an authorized HPE and HPE Juniper Networking reseller, Uniqcli can source both the SRX4300 and SRX1600 for public-sector buyers, including TAA-compliant configurations and procurement through GPC, SAP, FAR, and GSA eBuy vehicles. Contact us with your contract and quantity requirements for a quote.

Can Uniqcli help size and quote the right SRX model?

Yes. We can right-size the SRX4300 versus SRX1600 against your peak inspected throughput, interface mix, and session counts, then quote licensing, support, and high-availability pairs. We can source both models and their transceivers and services.
