Juniper SRX4300 vs Palo Alto PA-5400 Series: Data Center Firewall Comparison

The Juniper SRX4300 and the Palo Alto Networks PA-5400 Series both target high-throughput north-south inspection in the data center and at the internet edge. The SRX4300 leans on Junos OS, deep routing, and per-rack-unit density, while the PA-5400 Series leans on PAN-OS single-pass App-ID and a broad security subscription stack. This guide compares the two next-generation firewalls on throughput, ports, threat prevention, and total cost of ownership.

Get a quote See the specs

The short answer

Choose the Juniper SRX4300 if you want a 1U, power-dense firewall with strong Junos routing, native 100G MACsec interfaces, and tight integration into a Juniper or HPE Juniper Networking fabric. Choose the Palo Alto PA-5400 Series when App-ID-based application control, the breadth of Cloud-Delivered Security Services, and Panorama-centric operations are the priority and you can use the 2RU chassis and higher top-end throughput. For routing-heavy data center segmentation the SRX4300 is the value-dense pick; for security-platform depth and the largest single-box throughput ceiling, the PA-5400 leads.

Juniper SRX4300 vs Palo Alto PA-5400 Series, head to head

Juniper SRX4300

Palo Alto PA-5400 Series

Form factor and density

1U appliance delivering up to 90 Gbps firewall throughput per rack unitadvantage

2RU chassis; series scales to roughly 200 Gbps firewall throughput at the top model

Top-end throughput ceiling

Single SRX4300 tops out lower than the largest PA-5400, but is very dense per RU

Higher absolute firewall throughput at the top of the series (PA-5440/5445)advantage

Routing and SD-WAN

Full Junos OS routing stack (BGP, IS-IS, MPLS, EVPN-VXLAN) and AI-Predictive Threat Preventionadvantage

Capable routing for NGFW roles but less of a full router OS than Junos

Application and threat security

AppID, UserFW, IPS, and Content Security via Junos with ATP Cloud

Single-pass App-ID, Content-ID, User-ID, and broad Cloud-Delivered Security Servicesadvantage

Encryption at line rate

Wire-speed MACsec on all data ports, including 100G interfacesadvantage

MACsec support varies by interface; strong decryption and TLS inspection

Management and operations

Junos CLI, Security Director, and Juniper Mist cloud management

Mature Panorama centralized management and Strata Cloud Manageradvantage

Ecosystem fit

Integrates cleanly with Juniper / HPE Juniper Networking switching and routing

Best fit for organizations standardized on the Palo Alto security platform

Value per gigabit

High firewall throughput per rack unit in a compact 1U footprintadvantage

Premium platform pricing offset by subscription breadth

Specifications side by side

Vendor / family: Juniper SRX Series (SRX4300); Palo Alto Networks PA-5400 Series
Models compared: SRX4300; PA-5410 / PA-5420 / PA-5430 / PA-5440 / PA-5445
Form factor: 1U rack-mount appliance; 2RU rack-mount appliance
Operating system: Junos OS; PAN-OS
Firewall throughput: Up to ~90 Gbps per rack unit; ~52 Gbps (PA-5410) up to ~200 Gbps at top of series
Threat prevention throughput: Hardware-accelerated IPS / Content Security (see datasheet by feature mix); ~32 Gbps (PA-5410) scaling up across the series
Concurrent sessions: High session scale for data center inspection (per Junos datasheet); ~5M (PA-5410) up to higher counts on larger models
High-speed interfaces: 6x QSFP28 (100G), 4x SFP28 (25G), 8x SFP+ (10G), 8x 10GBASE-T multigig; High-speed 10/25/40/100G interface options depending on model
MACsec: Wire-speed MACsec on all data ports; Supported on select interfaces
NGFW services: AppID, UserFW, IPS, Content Security, AI-Predictive Threat Prevention; App-ID, Content-ID, User-ID, WildFire, Advanced Threat Prevention, URL Filtering, DNS Security
Cloud management: Juniper Security Director / Juniper Mist; Panorama / Strata Cloud Manager
High availability: Chassis cluster (active/active and active/passive); Active/active and active/passive HA

Where Juniper SRX4300 wins

1U power-dense design delivering up to ~90 Gbps firewall throughput per rack unit
Full Junos OS routing stack (BGP, IS-IS, MPLS, EVPN-VXLAN) for routing-heavy data center segmentation
Wire-speed MACsec across all data ports, including native 100G interfaces
Tight integration with Juniper / HPE Juniper Networking switching, routing, and Mist
AI-Predictive Threat Prevention and unified Junos operations

Where Palo Alto PA-5400 Series wins

Higher absolute firewall throughput at the top of the series for hyperscale edges
Single-pass App-ID architecture with deep application visibility and control
Broad Cloud-Delivered Security Services (WildFire, Advanced Threat Prevention, URL Filtering, DNS Security)
Mature Panorama centralized management for large multi-firewall estates
Strong TLS decryption and inspection capabilities

Which one should you buy?

High-density data center north-south inspection in limited rack space

Pick Juniper SRX4300. The 1U chassis delivers up to ~90 Gbps firewall throughput per rack unit with native 100G MACsec, maximizing throughput per RU.

Internet gateway needing the highest single-box throughput ceiling

Pick Palo Alto PA-5400 Series. Top-of-series PA-5440/5445 models reach roughly 200 Gbps firewall throughput for hyperscale edge inspection.

Routing-heavy segmentation in a Juniper or HPE Juniper Networking fabric

Pick Juniper SRX4300. Junos OS brings a complete routing stack (BGP, MPLS, EVPN-VXLAN) and consistent operations across the fabric.

Application-centric security with deep app control and threat intel breadth

Pick Palo Alto PA-5400 Series. Single-pass App-ID plus the full Cloud-Delivered Security Services suite gives granular application and threat coverage.

Centralized policy management across a large firewall estate

Pick Palo Alto PA-5400 Series. Panorama and Strata Cloud Manager provide mature multi-firewall policy and log management at scale.

Frequently asked

Is the Juniper SRX4300 faster than the Palo Alto PA-5400 Series?

It depends on the metric. The SRX4300 is extremely dense, delivering up to about 90 Gbps firewall throughput in a 1U chassis. The PA-5400 Series spans several models; entry models like the PA-5410 start near 52 Gbps firewall throughput, while top models such as the PA-5440/5445 reach roughly 200 Gbps. Compare on threat-prevention throughput with your specific feature set enabled, since that is what matters for data center inspection.

What is the form factor difference between the SRX4300 and PA-5400?

The SRX4300 is a 1U appliance, while PA-5400 Series firewalls are 2RU. If rack space and throughput-per-RU are priorities, the SRX4300 is more compact; the larger PA-5400 chassis trades space for a higher top-end throughput ceiling.

How do their security features compare?

The SRX4300 runs Junos OS with AppID, UserFW, IPS, Content Security, and AI-Predictive Threat Prevention through ATP Cloud. The PA-5400 Series runs PAN-OS with single-pass App-ID, Content-ID, User-ID, and Cloud-Delivered Security Services like WildFire, Advanced Threat Prevention, URL Filtering, and DNS Security. Both are full next-generation firewalls; the difference is platform philosophy and subscription packaging.

Which is better for a data center fabric?

For routing-heavy data center segmentation, the SRX4300 benefits from the full Junos OS routing stack (BGP, IS-IS, MPLS, EVPN-VXLAN) and wire-speed MACsec on all ports, and it integrates cleanly with Juniper and HPE Juniper Networking switching. The PA-5400 Series is strong where App-ID-based application control and the Palo Alto security platform are the standard.

Do these firewalls support 100G interfaces and MACsec?

Yes. The SRX4300 provides QSFP28 100G ports with wire-speed MACsec across all data ports. The PA-5400 Series offers high-speed interface options up to 100G depending on the model, with MACsec supported on select interfaces. Confirm exact port and MACsec details against the current datasheet for your model.

How are they managed?

The SRX4300 is managed via the Junos CLI, Juniper Security Director, and Juniper Mist for cloud-based operations. The PA-5400 Series uses Panorama for centralized management and Strata Cloud Manager. Organizations with large multi-firewall estates often value Panorama's mature policy and log consolidation.

Can Uniqcli help with TAA, GSA, or SAP/FAR channels procurement?

Yes. As an authorized HPE and HPE Juniper Networking reseller, we can source the Juniper SRX4300 and supporting infrastructure, and we can quote for TAA-compliant, GSA MAS (application in progress), and SAP/FAR channels procurement paths. We can also source comparable Palo Alto PA-5400 Series platforms on request so you can evaluate both. Contact us for a configured quote and contract-vehicle guidance.

Which firewall offers better value?

The SRX4300 typically wins on throughput-per-rack-unit and on value when you are standardized on Juniper or HPE Juniper Networking. The PA-5400 Series commands premium platform pricing but bundles a broad security subscription stack. The right answer depends on your existing ecosystem, required throughput with services enabled, and management preferences. Reach out for a side-by-side quote.
