Aruba AP-735 vs AP-655: Mid-Tier Wi-Fi 7 vs Flagship Wi-Fi 6E

The HPE Aruba Networking AP-735 is a tri-radio 2x2 Wi-Fi 7 campus access point, while the AP-655 is the tri-radio 4x4 Wi-Fi 6E flagship from the prior generation. The interesting tension: the AP-735 brings the newer 802.11be standard with MLO and 320 MHz channels but fewer spatial streams, whereas the AP-655 keeps 4x4 MIMO and 5 GbE-capable uplinks. This guide compares both side by side so you can decide whether a cost-aware Wi-Fi 7 refresh or the proven 6E flagship is the right call for your campus wireless.

Get a quote See the specs

The short answer

For new builds and refreshes that want future-proofing, the AP-735 wins on standard: Wi-Fi 7 features like Multi-Link Operation, 320 MHz channels, and 4K-QAM extend the platform's useful life and improve performance for next-gen clients. The AP-655 still wins where raw spatial-stream capacity and 5 GbE uplinks matter most: very high client density on 4x4-capable devices today, or sites that already standardized on the 650 Series. If budgets are tight and you mostly serve 2x2 client devices, the mid-tier AP-735 is the smarter long-term buy; if you need maximum per-AP capacity for current 6E clients, the AP-655 holds its ground.

Aruba AP-735 vs Aruba AP-655, head to head

Aruba AP-735

Aruba AP-655

Wi-Fi standard

Wi-Fi 7 (802.11be) with MLO, 320 MHz, 4K-QAMadvantage

Wi-Fi 6E (802.11ax), 160 MHz

MIMO / spatial streams

Tri-radio 2x2:2 per band

Tri-radio 4x4:4 per bandadvantage

Aggregate data rate

Up to ~9.3 Gbps (up to ~14.4 Gbps in dual-5/dual-6 modes)advantage

Up to ~7.8 Gbps

Uplink ports

Dual 2.5GbE (100/1000/2500BASE-T)

Dual HPE Smart Rate (1/2.5/5 GbE)advantage

IoT radios

Dual Bluetooth 5.4 + 802.15.4 (Zigbee), dual USBadvantage

Integrated BLE + Zigbee, USB

Future-proofing / platform longevity

Newer standard, longer runwayadvantage

Mature 6E platform nearing end of its curve

Per-AP density for current clients

2x2 limits peak per-client throughput

4x4 favors many high-end clients at onceadvantage

Best-fit deployment

Cost-aware Wi-Fi 7 refresh, mixed client mix

High-density 6E sites standardized on 650 Series

Specifications side by side

Wi-Fi generation: Wi-Fi 7 (802.11be); Wi-Fi 6E (802.11ax)
Bands: Tri-band: 2.4 / 5 / 6 GHz concurrent; Tri-band: 2.4 / 5 / 6 GHz concurrent
Radio architecture: Three 2x2:2 radios; Three 4x4:4 radios
Max aggregate rate: ~9.3 Gbps (up to ~14.4 Gbps flexible modes); ~7.8 Gbps
6 GHz peak rate: Up to ~5.8 Gbps (320 MHz, Wi-Fi 7); Up to ~4.8 Gbps (HE160)
5 GHz peak rate: Up to ~2.9 Gbps; Up to ~2.4 Gbps (HE80)
2.4 GHz peak rate: Up to ~688 Mbps; Up to ~1.147 Gbps (HE40)
Key Wi-Fi 7 features: MLO, 320 MHz channels, 4K-QAM; Not supported (Wi-Fi 6E)
Ethernet uplinks: Dual 2.5GbE (NBASE-T / 802.3bz); Dual HPE Smart Rate 1/2.5/5 GbE
PoE: 802.3bt Class 5 (full features); 802.3at with restrictions; 802.3bt Class 5 or dual 802.3at (full features)
IoT / BLE: Dual Bluetooth 5.4 + 802.15.4 Zigbee, dual USB; Integrated BLE + Zigbee, USB
Management: HPE Aruba Networking Central; AOS-10; HPE Aruba Networking Central; AOS-10

Where Aruba AP-735 wins

Wi-Fi 7 (802.11be) with MLO, 320 MHz channels, and 4K-QAM for higher throughput and lower latency
Newer standard means a longer support runway and better future-proofing for a refresh
Flexible dual-5 GHz / dual-6 GHz radio modes push aggregate capacity to ~14.4 Gbps
Dual Bluetooth 5.4 plus 802.15.4 (Zigbee) and dual USB for richer IoT integration
Mid-tier positioning makes Wi-Fi 7 affordable across more of the floor plan

Where Aruba AP-655 wins

4x4:4 MIMO on every band for more spatial streams and stronger per-AP capacity with 4x4 clients
Dual HPE Smart Rate ports support up to 5 GbE, easing wired-uplink bottlenecks
Higher 2.4 GHz peak rate (HE40) benefits legacy and IoT-heavy environments
Proven, widely deployed 650 Series platform with established AOS-10 feature support
Strong fit for sites already standardized on AP-655 for spares and consistency

Which one should you buy?

New campus build wanting the longest useful AP lifespan

Pick Aruba AP-735. Wi-Fi 7 with MLO and 320 MHz extends the platform's runway and benefits the next wave of client devices, justifying a forward-looking standard over capacity you may not use yet.

Very high-density area with many high-end 4x4 6E clients today

Pick Aruba AP-655. 4x4:4 radios provide more spatial streams to serve demanding current clients concurrently, and 5 GbE uplinks avoid wired bottlenecks under load.

Cost-aware refresh across a large floor plan with mixed 2x2 clients

Pick Aruba AP-735. Most laptops, phones, and tablets are 2x2, so the AP-735 captures Wi-Fi 7 gains where they matter while keeping per-AP cost in check across many radios.

Adding APs to a site already standardized on the 650 Series

Pick Aruba AP-655. Matching the installed base keeps RF design, spares, and AOS-10 configuration consistent, simplifying operations until a full Wi-Fi 7 cutover is planned.

IoT-rich deployment needing BLE, Zigbee, and USB peripherals

Pick Aruba AP-735. Dual Bluetooth 5.4 plus 802.15.4 radios and dual USB ports give more headroom for location services and connected-device gateways.

Frequently asked

What is the main difference between the Aruba AP-735 and AP-655?

The AP-735 is a Wi-Fi 7 (802.11be) access point with MLO, 320 MHz channels, and 4K-QAM but uses 2x2 radios, while the AP-655 is a Wi-Fi 6E (802.11ax) flagship with 4x4 radios and 5 GbE-capable uplinks. The AP-735 trades spatial streams for the newer standard.

Is the AP-735 faster than the AP-655?

On aggregate data rate, yes: the AP-735 reaches roughly 9.3 Gbps (and up to ~14.4 Gbps in flexible dual-radio modes) versus about 7.8 Gbps for the AP-655. But the AP-655's 4x4 radios can serve more spatial streams to capable clients at once, so real-world results depend on your client mix and channel widths.

Should I buy the Wi-Fi 7 AP-735 or stick with the Wi-Fi 6E AP-655?

Choose the AP-735 for new builds and refreshes where future-proofing and Wi-Fi 7 features matter, and most clients are 2x2. Choose the AP-655 when you need maximum 4x4 capacity for current 6E clients, want 5 GbE uplinks, or are extending a site already on the 650 Series.

Do the AP-735 and AP-655 use the same management platform?

Yes. Both are managed by HPE Aruba Networking Central and run under AOS-10, so they can coexist in the same environment and share a common operational model during a phased migration.

What PoE do the AP-735 and AP-655 require?

Both operate without restrictions on 802.3bt (Class 5) PoE. The AP-655 can also run full features on dual (combined) 802.3at, while the AP-735 will restrict certain functions like USB ports when powered by a single 802.3at source. Verify your switch's PoE budget when planning.

Does the AP-655 support Wi-Fi 7 features like MLO?

No. The AP-655 is a Wi-Fi 6E (802.11ax) access point and does not support Wi-Fi 7 features such as Multi-Link Operation, 320 MHz channels, or 4K-QAM. Those capabilities require the Wi-Fi 7 AP-735 or another 730 Series model.

Which AP is better for high-density environments?

It depends on the clients. For dense areas with many high-end 4x4 6E devices, the AP-655's extra spatial streams and 5 GbE uplinks help. For dense areas with mostly 2x2 clients, the AP-735 delivers Wi-Fi 7 efficiency gains while keeping cost per AP lower across the coverage area.

Can Uniqcli supply these APs on TAA-compliant GPC, SAP, or FAR-based orders?

Yes. As an authorized HPE and HPE Aruba Networking reseller, Uniqcli can source the AP-735, AP-655, matching licenses, and PoE switching, and we can quote against TAA-compliant, GSA, and SAP/FAR channels procurement vehicles. Contact us with your bill of materials and contract requirements and we will price it.
