Juniper SRX5K-SCB3 Switch Control Module

Juniper SRX5K-SCB3 Switch Control Module - For Optical Network, Data NetworkingOptical Fiber10 Gigabit Ethernet - 10GBase-X - 2 x Expansion Slots (part number SRX5K-SCB3) is supplied by Uniqcli, an authorized HPE & Juniper partner, in the Juniper Modules category. Ethernet Technology: 10 Gigabit Ethernet.

The SRX5K-SCB3 (SCB3) caters to high-end security markets requiring support for higher capacity traffic, greater interface density (slot and capacity scale), and improved services. The SCB3 is supported on SRX5400, SRX5600, and SRX5800 Services Gateways. The SCB3 supports the standard midplane and the enhanced midplane. Some key attributes of the SCB3 are: With the existing midplane and fabric link speed of 8.36 Gbps, supports a bandwidth of 205 Gbps per slot with redundant fabric support and 308 Gbps per slot without redundancy. With the enhanced midplane and fabric link speed of 10.2 Gbps, supports a bandwidth of 249 Gbps per slot with redundant fabric support and 374 Gbps per slot without redundancy with the enhanced midplane Improved fabric performance with the next-generation fabric (XF2) chip. Full performance with fabric redundancy for higher-capacity line cards. Support for MPC line cards such as SRX5K-MPC (IOC2) and IOC3 (SRX5K-MPC3-40G10G or SRX5K-MPC3-100G10G) only. Two 10-Gigabit Ethernet SFP+ ports (These ports are disabled and reserved for future use).

• Switch Control Module offers enhanced dependability with maximum productivity • With 10GBase-X technology, enjoy up to 10Gbps data transfer rate over supported network cable • Enjoy flexibility and scalability with data transfer rate of up to 10 Gbps with 10 Gigabit Ethernet technology • Optical Fiber media support for efficient and reliable connectivity • Switch Control Module with optical network application/usage for maximum dependability and convenience

Key specifications: Ethernet Technology: 10 Gigabit Ethernet · Media Type Supported: Optical Fiber · Network Technology: 10GBase-X · Application/Usage: Optical Network, Data Networking · Total Number of Expansion Slots: 2 · Expansion Slot Type: SFP+ · Compatibility: Juniper Networks Services Gateway: SRX5400 SRX5600 SRX5800 · Product Type: Switch Control Module.

GPC-payable, with SAP, FAR-based purchase orders, and GSA eBuy support. Ask us about TAA-compliant configurations, current pricing, stock, and lead time.
