Representative imageHPE AP-615 Tri Band IEEE 802.11 a/b/g/n/ac/ax 3.60 Gbit/s Wireless Access Point
HPE AP-615 Tri Band IEEE 802.11 a/b/g/n/ac/ax 3.60 Gbit/s Wireless Access Point - Indoor - 2.40 GHz, 5 GHz, 6 GHz - Internal - MIMO Technology - 2 x Network (RJ-45) - 2.5 Gigabit Ethernet - PoE Ports - Bluetooth 5 - 5.60 W - Ceiling Mountable - 1
● Ships on backorderFree US shipping3-day delivery30-day returns
Advertised price · GPC-payable · TAA-compliant configurations available.
Free download
Documents
- Product Type
- Wireless Access Point
- Network Band
- Tri Band
- Frequency Band
- 2.40 GHz
- Frequency Band
- 5 GHz
- Frequency Band
- 6 GHz
- Antenna Form Factor
- Internal
- Wireless LAN Standard
- IEEE 802.11 a/b/g/n/ac/ax
- Bluetooth Standard
- Bluetooth 5
Overview
HPE AP-615 Tri Band IEEE 802.11 a/b/g/n/ac/ax 3.60 Gbit/s Wireless Access Point - Indoor - 2.40 GHz, 5 GHz, 6 GHz - Internal - MIMO Technology - 2 x Network (RJ-45) - 2.5 Gigabit Ethernet - PoE Ports - Bluetooth 5 - 5.60 W - Ceiling Mountable - 1 (part number R7J47A) is supplied by Uniqcli, an authorized HPE partner, in the HPE Wireless Access Points/Bridges category. Network Band: Tri Band.
ARUBA 610 SERIES WI-FI 6E CAMPUS ACCESS POINTS | Fast, resilient, and secure Wi-Fi 6E connectivity in a compact and affordable platform For enterprises who need more wireless capacity and/or wider channels, Aruba 610 Series Campus APs are designed to take advantage of the newly available 6 GHz spectrum using a unique dual-radio/tri-band architecture. Adding support for the 6 GHz band to the traditional 2.4 GHz and 5 GHz bands more than doubles the available wireless capacity in a wireless network - so you can meet growing demand due to bandwidth-hungry video, increasing numbers of client and IoT devices, and growth in cloud. Unique to Aruba, the 610 Series features two radios that can be tuned to any two of the three available spectrum bands for Wi-Fi (2.4 GHz, 5 GHz, 6 GHz). This flexibility provides a cost-effective and compact platform that delivers full tri-band coverage as part of a multi-AP deployment and can be used with software that will intelligently and flexibly configure the radios of each of these dual-radio APs. More capacity and wider channels The Aruba 610 Series APs are designed to take advantage of Wi-Fi 6E and the 6 GHz band, which translates into far greater speeds, wider channels for multi-gigabit traffic, and less interference. Its two 2x2 MIMO radios deliver a combined peak data rate of up to 3.6 Gbps when configured for concurrent 5 GHz and 6 GHz operation. Advantages of 6 GHz Wi-Fi 6E provides up to 1200 MHz of additional unlicensed spectrum in the 6 GHz band for higher throughput and improved application performance. With up to seven 160 MHz channels, Wi-Fi 6E can better support low-latency, bandwidth hungry applications like high-definition video and augmented reality/virtual reality applications. Only Wi-Fi 6E capable devices can use the 6 GHz band so there is no interference or slowdowns due to legacy devices. Device class support The Aruba 610 Series APs are part of the low power indoor (LPI) device class. This fixed indoor-only class uses lower power levels and does not require an Automated Frequency Coordination service (AFC) to manage incumbent outdoor services, which is required for standard class APs. Global readiness While the need for more Wi-Fi capacity is recognized across the globe, countries are approaching the 6 GHz band differently. The 610 Series APs are set up to automatically update regulatory rules once Wi-Fi 6E regulations have been approved and certified. Extend the benefits of Wi-Fi 6 The Aruba 610 Series APs are based on the 802.11ax (Wi-Fi 6) standard, which means that all its efficiency and security enhancements are also available on the 6 GHz band. Wi-Fi 6 features such as Orthogonal Frequency Division Multiple Access (OFDMA), BSS coloring etc. are fully supported on the Aruba Wi-Fi 6E access points as well.
• Unlocks the 6 GHz band to more than double the available capacity in wireless networks • Comprehensive dual radio/tri-band coverage across 2.4 GHz, 5 GHz, and 6 GHz to deliver up to 3.6 Gbps combined peak data rate • Compact and low power consumption - virtually unrestricted operation from an 802.3af (class 3) PoE source • Up to seven 160 MHz channels in 6 GHz to support low-latency, bandwidth-hungry applications like high-definition video, and augmented reality/virtual reality applications • 2.5 Gbps Smart Rate Ethernet port to minimize wired bottlenecks
Key specifications: Network Band: Tri Band · Frequency Band: 2.40 GHz Hz, 5 GHz Hz, 6 GHz Hz · Wireless LAN Standard: IEEE 802.11 a/b/g/n/ac/ax · Bluetooth Standard: Bluetooth 5 · Encryption Standard: WPA, WPA2, WPA3, WPA3-SAE, WPA2-MPSK, WPA3-ENT · Data Encryption: Yes · MIMO Technology: Yes · Beamforming Technology: Yes.
GPC-payable, with SAP, FAR-based purchase orders, and GSA eBuy support. Ask us about TAA-compliant configurations, current pricing, stock, and lead time.
Tech specs
Technical Information
- Network Band
- Tri Band
- Frequency Band
- 2.40 GHz Hz, 5 GHz Hz, 6 GHz Hz
- Wireless LAN Standard
- IEEE 802.11 a/b/g/n/ac/ax
- Bluetooth Standard
- Bluetooth 5
- Encryption Standard
- WPA, WPA2, WPA3, WPA3-SAE, WPA2-MPSK, WPA3-ENT
- Data Encryption
- Yes
- MIMO Technology
- Yes
- Beamforming Technology
- Yes
- Indoor/Outdoor
- Indoor
- Wireless Transmission Speed
- 3.60 Gbit/s Bps
Interfaces/Ports
- Ethernet Technology
- 2.5 Gigabit Ethernet
- USB
- Yes
- Number of Network (RJ-45) Ports
- 2
- USB Standard
- USB 2.0
- Management Port
- Yes
- PoE (RJ-45) Port
- Yes
- PoE PD Port
- Yes
Warranty
- Limited Warranty
- Lifetime
Physical Characteristics
- Antenna Form Factor
- Internal
- Height
- 1.5" mm
- Width
- 6.3" mm
- Depth
- 6.3" mm
- Form Factor
- Ceiling Mountable
- Weight (Approximate)
- 1.15 lb g
Power Description
- Power Consumption
- 5.60 W W
General Information
- Product Type
- Wireless Access Point
- Product Series
- 610
- Product Model
- AP-615
- Packaged Quantity
- 1
