Aruba CX 6200F 48G Class-4 PoE 4SFP+ 740W Switch - 48 Ports - Manageable - Gigabit Ethernet, 10 Gigabit Ethernet - 10/100/100Representative image
Transceivers & Cables

Aruba CX 6200F 48G Class-4 PoE 4SFP+ 740W Switch

Aruba CX 6200F 48G Class-4 PoE 4SFP+ 740W Switch - 48 Ports - Manageable - Gigabit Ethernet, 10 Gigabit Ethernet - 10/100/1000Base-T, 1000Base-X, 10GBase-X - 3 Layer Supported - Modular - 76 W Power Consumption - 740 W PoE Budget - Twisted Pair, Optical Fiber - PoE Ports - Gray - Rack-mountable - Lifetime Limited Warranty

Mfr #: JL728B#B2B
$13,446Save $3,024.23 (22%)
$10,421.77

● Ships on backorderFree US shipping3-day delivery30-day returns

Advertised price · GPC-payable · TAA-compliant configurations available.

Free download

Documents

Product Type
Ethernet Switch
Manageable
Yes
Ethernet Technology
Gigabit Ethernet
Ethernet Technology
10 Gigabit Ethernet
Product Family
CX 6200
Stack Port
Yes
Media Type Supported
Twisted Pair
Media Type Supported
Optical Fiber

Overview

Aruba CX 6200F 48G Class-4 PoE 4SFP+ 740W Switch - 48 Ports - Manageable - Gigabit Ethernet, 10 Gigabit Ethernet - 10/100/1000Base-T, 1000Base-X, 10GBase-X - 3 Layer Supported - Modular - 76 W Power Consumption - 740 W PoE Budget - Twisted Pair, Optical Fiber - PoE Ports - Gray - Rack-mountable - Lifetime Limited Warranty (part number JL728B#B2B) is supplied by Uniqcli, an authorized HPE partner, in the HPE Switches & Bridges category. Manageable: Yes.

The HPE Aruba Networking CX 6200 Switch Series is a next-gen family of stackable access switches ideal for enterprise branch offices, campuses, and SMB networks. Features | Maximize your HPE Aruba Networking CX 6200 Switch Series | What's New Enterprise-class connectivity with support for ACLs, robust QoS, and common protocols such as static and Access OSPF routing. Up to 384 ports of scalability with 8-member VSF stacking. 24 and 48-port fixed and modular switches can stack together with easy to deploy through the CX Mobile app. Models include modular switches with 1/10 GbE uplinks, LRM, and MACSec 256, fixed switches with either 1/10 GbE SFP+ or 1 GbE SFP uplinks, and options that support 30W to 60W of PoE per port. Intelligent monitoring and visibility via HPE Aruba Networking CX Network Analytics Engine. HPE Aruba Networking Switch Multi-Edit Software support for automation, configuration and verification. Dynamic Segmentation enables secure access for users and IoT. Flexible, modular switch models support hot-swappable, redundant power supplies and fans for enhanced resiliency.

• Effectively reduces downtime with improved network performance • Conveniently lets you connect two standard Ethernet ports to ensure maximum efficiency • Provides efficient communication with other ethernet switch in the stack to ensure maximum productivity • Features 48 networking ports to meet the requirements of the most demanding workgroups • Supports layer 3 switching for enhanced performance and usability

Key specifications: Manageable: Yes · Maximum Data Transfer Rate: 1.25 GB/s Bps · Ethernet Technology: Gigabit Ethernet, 10 Gigabit Ethernet · Media Type Supported: Twisted Pair, Optical Fiber · Network Technology: 10/100/1000Base-T, 1000Base-X, 10GBase-X · Network (RJ-45): Yes · Modular: Yes · Uplink Port: Yes.

GPC-payable, with SAP, FAR-based purchase orders, and GSA eBuy support. Ask us about TAA-compliant configurations, current pricing, stock, and lead time.

Tech specs

Management & Protocols
Manageable
Yes
Media & Performance
Maximum Data Transfer Rate
1.25 GB/s Bps
Ethernet Technology
Gigabit Ethernet, 10 Gigabit Ethernet
Media Type Supported
Twisted Pair, Optical Fiber
Network Technology
10/100/1000Base-T, 1000Base-X, 10GBase-X
Interfaces/Ports
Network (RJ-45)
Yes
Modular
Yes
Uplink Port
Yes
Stack Port
Yes
Total Number of Network Ports
48
Port/Expansion Slot Details
48 x 10/100/1000BASE-T Gigabit Ethernet PoE RJ-45 Network Port, 4 x 1/10 SFP Gigabit Ethernet Expansion Slot, 1 x Out-of-Band Management Port, 1 x USB Type-A Host Port, 1 x RJ-45 Console Port
Power Description
PoE (RJ-45) Port
Yes
Redundant Power Supply Supported
Yes
PoE Budget
740 W W
Power Consumption
76 W W
Input Voltage
120 V AC, 230 V AC
Power Source
Power Supply, AC, PoE+, PoE
Network & Communication
Networking Standards
IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az
Layer Supported
3
Physical Characteristics
Product Color
Gray
Height
1.7" mm
Width
17.4" mm
Depth
12.9" mm
Form Factor
Rack-mountable
Weight (Approximate)
11.24 lb g
Warranty
Limited Warranty
Lifetime
I/O Expansions
Number of SFP+ Slots
4
Total Number of Expansion Slots
4
Expansion Slot Type
SFP, SFP+
Miscellaneous
Energy Star
No
TCO Certified
No
Environmental Compliance
Restriction of Hazardous Substances (RoHS)
Technical Information
Features
VSF Stacking, Intelligent monitoring, Hot-swappable
General Information
Product Type
Ethernet Switch
Product Series
CX 6200
Product Model
6200F
Packaged Quantity
1
