Aruba AP-534 Dual Band Wi-Fi 5 IEEE 802.11ac 3.55 Gbit/s Wireless Access Point - TAA Compliant - 2.40 GHz, 5 GHz - MIMO TechnRepresentative image
Transceivers & Cables

Aruba AP-534 Dual Band Wi-Fi 5 IEEE 802.11ac 3.55 Gbit/s Wireless Access Point

Aruba AP-534 Dual Band Wi-Fi 5 IEEE 802.11ac 3.55 Gbit/s Wireless Access Point - TAA Compliant - 2.40 GHz, 5 GHz - MIMO Technology - 2 x Network (RJ-45) - 5 Gigabit Ethernet - Bluetooth 5 - Wall Mountable, Ceiling Mountable, Rail-mountable

Mfr #: JZ332AR
Request a price

GPC-payable · TAA-compliant configuration on request · usually back within one business day.

Detailed quote

Free download

Documents

Product Type
Wireless Access Point
Network Band
Dual Band
Frequency Band
2.40 GHz
Frequency Band
5 GHz
Wireless LAN Standard
IEEE 802.11ac
Bluetooth Standard
Bluetooth 5
Ethernet Technology
5 Gigabit Ethernet
USB
Yes

Overview

Aruba AP-534 Dual Band Wi-Fi 5 IEEE 802.11ac 3.55 Gbit/s Wireless Access Point - TAA Compliant - 2.40 GHz, 5 GHz - MIMO Technology - 2 x Network (RJ-45) - 5 Gigabit Ethernet - Bluetooth 5 - Wall Mountable, Ceiling Mountable, Rail-mountable (part number JZ332AR) is supplied by Uniqcli, an authorized HPE partner, in the HPE Wireless Access Points/Bridges category. Network Band: Dual Band.

2.40 GHz, 5 GHz - MIMO Technology - 2 x Network (RJ-45) - 5 Gigabit Ethernet - Bluetooth 5 - Wall Mountable, Ceiling Mountable, Rail-mountable

• AI-powered features for wireless RF and client connectivity optimization • Dual-radio (dual 4x4 MIMO) 802.11ax AP with up-and downlink OFDMA* and Multi-User MIMO (MU-MIMO) • Supports all mandatory and several optional 802.11ax features, and up to the full 37 OFDMA Resource Units (RUs) • Maximum data rates of 2.4Gbps in the 5GHz band and 1,150Mbps in the 2.4GHz band (for an aggregate peak data rate of 3.55Gbps) • Up to 1,024 associated client devices per radio

Key specifications: Network Band: Dual Band · Frequency Band: 2.40 GHz Hz, 5 GHz Hz · Wireless LAN Standard: IEEE 802.11ac · Bluetooth Standard: Bluetooth 5 · MIMO Technology: Yes · Beamforming Technology: Yes · Wireless Transmission Speed: 3.55 Gbit/s Bps · Ethernet Technology: 5 Gigabit Ethernet.

GPC-payable, with SAP, FAR-based purchase orders, and GSA eBuy support. Ask us about TAA-compliant configurations, current pricing, stock, and lead time.

Tech specs

Technical Information
Network Band
Dual Band
Frequency Band
2.40 GHz Hz, 5 GHz Hz
Wireless LAN Standard
IEEE 802.11ac
Bluetooth Standard
Bluetooth 5
MIMO Technology
Yes
Beamforming Technology
Yes
Wireless Transmission Speed
3.55 Gbit/s Bps
Interfaces/Ports
Ethernet Technology
5 Gigabit Ethernet
USB
Yes
Number of Network (RJ-45) Ports
2
PoE PD Port
Yes
Network & Communication
Wi-Fi Generation
Wi-Fi 5
Physical Characteristics
Height
2.2" mm
Width
9.4" mm
Depth
9.4" mm
Form Factor
Wall Mountable, Ceiling Mountable, Rail-mountable
Weight (Approximate)
2.20 lb g
General Information
Product Type
Wireless Access Point
Product Condition
Refurbished
Product Series
530
Product Model
AP-534
Miscellaneous
TAA Compliant
Yes
