Representative imageHPE ProLiant DL385 G11 2U Rack Server
HPE ProLiant DL385 G11 2U Rack Server - 1 x AMD EPYC 9124 3 GHz - 32 GB RAM - 12Gb/s SAS Controller - AMD Chip - 2 Processor Support - 6 TB RAM Support - DDR5 SDRAM Up to 16 MB Graphic Card - Gigabit Ethernet - 8 x Total Bay(s) - 8 x SFF Bay(s) - Hot Swappable Bays - 1 x 800 W
GPC-payable · TAA-compliant configuration on request · usually back within one business day.
Free download
Documents
- Product Type
- Server
- Processor Core
- Hexadeca-core (16 Core)
- Environmentally Friendly
- Yes
- Processor Manufacturer
- AMD
- Number of Processors Supported
- 2
- Number of Processors Installed
- 1
- Ethernet Technology
- Gigabit Ethernet
- Maximum Power Supply Wattage
- 800 W
Overview
HPE ProLiant DL385 G11 2U Rack Server - 1 x AMD EPYC 9124 3 GHz - 32 GB RAM - 12Gb/s SAS Controller - AMD Chip - 2 Processor Support - 6 TB RAM Support - DDR5 SDRAM Up to 16 MB Graphic Card - Gigabit Ethernet - 8 x Total Bay(s) - 8 x SFF Bay(s) - Hot Swappable Bays - 1 x 800 W (part number P66781-B21) is supplied by Uniqcli, an authorized HPE partner, in the HPE Servers category. Cache: 64 MB Byte.
Overview | HPE ProLiant DL385 Gen11 The new HPE ProLiant DL385 Gen11 server is an accelerator-optimized 2U 2P solution that delivers exceptional compute performance, upgraded high-speed data transfer rate and memory depth at 2P compute capability. Powered by 4th Generation AMD EPYC? 9004 Series Processors with up to 96 cores, increased memory bandwidth (up to 6TB), high-speed PCIe Gen5 I/O, Gen5 EDSFF storage and the newly designed chassis supporting 8 single wide (SW) or 4 double wide (DW) GPUs*. The HPE ProLiant DL385 Gen11 server is a perfect accelerator-optimized 2U 2P solution.
• Powered by the 4th Generation AMD EPYC? 9004 Series Processors with 5nm technology that supports up to 128 cores at 400W, 1152 MB of L3 Cache, and 24 DIMMs for DDR5 memory up to 4800 MT/s. • 12 DIMM channels per processor for up to 6 TB total DDR5 memory with increased memory bandwidth and performance, and lower power requirements. • Advanced data transfer rates and higher network speeds from the PCIe Gen5 serial expansion bus, with up to 2x16 PCIe Gen5 and two OCP slots. • Includes HPE Integrated Lights-Out 6 (iLO 6) server management software that enables you to securely configure, monitor, and update your HPE ProLiant Gen11 servers seamlessly from anywhere. • Supports hot-pluggable, high-availability RAID M.2 boot options.
Key specifications: Cache: 64 MB Byte · Processor Core: Hexadeca-core (16 Core) · Processor Manufacturer: AMD · Number of Processors Supported: 2 · Number of Processors Installed: 1 · Processor Generation: 4th Gen · Processor Model: 9124 · Processor Speed: 3 GHz Hz.
GPC-payable, with SAP, FAR-based purchase orders, and GSA eBuy support. Ask us about TAA-compliant configurations, current pricing, stock, and lead time.
Tech specs
Processor
- Cache
- 64 MB Byte
- Processor Core
- Hexadeca-core (16 Core)
- Processor Manufacturer
- AMD
- Number of Processors Supported
- 2
- Number of Processors Installed
- 1
- Processor Generation
- 4th Gen
- Processor Model
- 9124
- Processor Speed
- 3 GHz Hz
- Processor Type
- EPYC
Warranty
- Additional Warranty Information
- 3-year parts, 3-year labor, 3-year onsite support with next business day response.
- Limited Warranty
- 3 Year Year
Miscellaneous
- Environmentally Friendly
- Yes
- Energy Star
- Yes
- Energy Efficiency Certification
- ENERGY STAR 3.0
- Environmental Compliance
- Waste Electrical and Electronic Equipment Directive (WEEE)
- Security Features
- UEFI Secure Boot and Secure Start support Immutable Silicon Root of Trust FIPS 140-3 validation (iLO 6 certification in progress) Common Criteria certification (iLO 6 certification in progress) Configurable for PCI DSS compliance Advanced Encryption Standard (AES) and Triple Data Encryption Standard (3DES) on browser Support for Commercial National Security Algorithms (CNSA) Tamper-free updates - components digitally signed and verified Secure Recovery - recover critical firmware to known good state on detection of compromised firmware Ability to rollback firmware Secure erase of NAND/User data TPM (Trusted Platform Module) 2.0
- Package Contents
- ProLiant DL385 Gen11 9124 3.0GHz 16-core 1P 32GB-R 8SFF 800W PS Server 6-foot IEC C-13/C-14 Jumper Cord
Chipset
- Chipset Manufacturer
- AMD
I/O Expansions
- Number of Internal 2.5" Bays
- 8
- Number of Total Expansion Bays
- 8
- Total Number of Expansion Slots
- 3
- Hot Swappable Bays
- Yes
- Number of SFF Bays
- 8
- PCI Express Details
- 2 OCP 3.0, 1 PCIe Gen5 x16
Network & Communication
- Ethernet Technology
- Gigabit Ethernet
Memory
- Number of Occupied Memory Slots
- 1
- Total Number of Memory Slots
- 12
- Memory Technology
- DDR5 SDRAM
- Error Checking
- ECC
- Maximum Memory Supported
- 6 TB Byte
- Signal Processing
- Registered (Buffered)
- Standard Memory
- 32 GB Byte
Controllers
- Controller Model
- MR408i-o
- Controller Type
- 12Gb/s SAS
Physical Characteristics
- Height
- 3.4" mm
- Width
- 17.1" mm
- Depth
- 25.4" mm
- Rack Height
- 2U
- Form Factor
- Rack
- Weight (Approximate)
- 73.63 lb g
Operating System
- Operating System Supported
- Windows Server 2019, Windows Server 2022, Red Hat Enterprise Linux 8.6, Red Hat Enterprise Linux 9.0, SUSE Linux Enterprise Server 15 SP4
Power Description
- Number of Power Supplies Supported
- 2
- Number of Power Supplies Installed
- 1
- Hot Swappable Power Supply
- Yes
- Maximum Power Supply Wattage
- 800 W W
- Plug/Connector Type
- C13/C14
Interfaces/Ports
- Number of Network (RJ-45) Ports
- 4
- Network (RJ-45)
- Yes
- Remote Management
- Yes
- Total Number of USB Ports
- 4
- Remote Management Controller
- HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download); HPE iLO Advanced, HPE iLO Advanced Premium Security Edition, and HPE OneView Advanced (require licenses) Compute Ops Management Software
Display & Graphics
- Graphics Memory Capacity
- 16 MB Byte
General Information
- Product Type
- Server
- Product Series
- DL385 G11
