Representative imageHPE ProLiant DL360 Gen12 1U Rack Server
HPE ProLiant DL360 Gen12 1U Rack Server - 1 x Intel Xeon 6 6505P 2.20 GHz - 64 GB RAM - 1.88 TB SSD - (2 x 960GB) SSD Configuration - Serial ATA/600, 12Gb/s SAS, NVMe Controller - Intel Chip - 2 Processor Support - 8 TB RAM Support - DDR5 SDRAM - 0, 1, 5, 6, 10, 50, 60 RAID Levels Up to 16 MB Graphic Card - Gigabit Ethernet - 8 x Total Bay(s) - 8 x SFF Bay(s) - Hot Swappable Bays - 2 x 800 W - Redundant Power Supply
GPC-payable · TAA-compliant configuration on request · usually back within one business day.
Free download
Documents
- Product Type
- Server
- Processor Core
- Dodeca-core (12 Core)
- Processor Manufacturer
- Intel
- Redundant Power Supply
- Yes
- Number of Processors Supported
- 2
- Number of Processors Installed
- 1
- RAID Supported
- Yes
- Ethernet Technology
- Gigabit Ethernet
Overview
HPE ProLiant DL360 Gen12 1U Rack Server - 1 x Intel Xeon 6 6505P 2.20 GHz - 64 GB RAM - 1.88 TB SSD - (2 x 960GB) SSD Configuration - Serial ATA/600, 12Gb/s SAS, NVMe Controller - Intel Chip - 2 Processor Support - 8 TB RAM Support - DDR5 SDRAM - 0, 1, 5, 6, 10, 50, 60 RAID Levels Up to 16 MB Graphic Card - Gigabit Ethernet - 8 x Total Bay(s) - 8 x SFF Bay(s) - Hot Swappable Bays - 2 x 800 W - Redundant Power Supply (part number P89231-DM5) is supplied by Uniqcli, an authorized HPE partner, in the HPE Servers category. Cache: 48 MB Byte.
This compact, rack-optimized two-socket server supports hybrid cloud workloads. The HPE ProLiant Compute DL360 Gen12 is a compact 1U 2P server that delivers exceptional compute performance, memory density with scalability and high-speed data transfer rates to run your most demanding applications. This server offers the right balance of expandability and density.
• 2 processors supported for optimal performance and maximum reliability in mission-critical server environments • With 64 GB memory, improve system performance to execute complex applications smoothly and shorten processing time • 1.88 TB SSD provides generous storage for all your critical data, supporting fast performance and dependable operations • 800 W power supply unit (PSU) included for hassle-free deployment and reliable power delivery in server environments • Xeon 6 processor works with modern DDR5 memory technologies, helping data move quickly so apps stay responsive during sustained activity
Key specifications: Cache: 48 MB Byte · Processor Core: Dodeca-core (12 Core) · Processor Manufacturer: Intel · Number of Processors Supported: 2 · Number of Processors Installed: 1 · Processor Model: 6505P · Processor Speed: 2.20 GHz Hz · Processor Type: Xeon 6.
GPC-payable, with SAP, FAR-based purchase orders, and GSA eBuy support. Ask us about TAA-compliant configurations, current pricing, stock, and lead time.
Tech specs
Processor
- Cache
- 48 MB Byte
- Processor Core
- Dodeca-core (12 Core)
- Processor Manufacturer
- Intel
- Number of Processors Supported
- 2
- Number of Processors Installed
- 1
- Processor Model
- 6505P
- Processor Speed
- 2.20 GHz Hz
- Processor Type
- Xeon 6
Chipset
- Chipset Manufacturer
- Intel
Power Description
- Number of Power Supplies Supported
- 2
- Number of Power Supplies Installed
- 2
- Redundant Power Supply
- Yes
- Hot Swappable Power Supply
- Yes
- Maximum Power Supply Wattage
- 800 W W
- Input Voltage
- 120 V AC V AC, 230 V AC V AC
I/O Expansions
- Number of Internal 2.5" Bays
- 8
- Number of Total Expansion Bays
- 8
- Total Number of Expansion Slots
- 3
- Hot Swappable Bays
- Yes
- Number of SFF Bays
- 8
- PCI Express Details
- 3 PCIe Gen5 slots (x16 lanes/each)
Controllers
- RAID Supported
- Yes
- Controller Model
- MR408i-o
- RAID Levels
- 0, 1, 5, 6, 10, 50, 60
- Controller Type
- Serial ATA/600, 12Gb/s SAS, NVMe
Network & Communication
- Ethernet Technology
- Gigabit Ethernet
Miscellaneous
- Energy Star
- Yes
- Energy Efficiency Certification
- ENERGY STAR 4.0
- Energy Efficiency Compliance
- Energy-related Products Directive Lot 9 (ErP Lot 9)
- Environmental Compliance
- Waste Electrical and Electronic Equipment Directive (WEEE)
- Security Features
- Secure Boot and Secure Start enable enhanced security Embedded UEFI Shell Operating system specific functionality Mass Configuration Deployment Tool using iLO RESTful API that is Redfish API Conformant Support for > 2.2 TB (using GPT) boot drives PXE boot support for IPv6 networks USB 3.2 Gen1 Stack Workload Profiles for simple performance optimization TPM 2.0 Support HTTP / HTTPS Boot iSCSI Software Initiator Support NVMe Boot Support Boot Support for UEFI Option ROM Only
- Package Contents
- ProLiant DL360 G12 Server ProLiant DL3XX Gen11 Easy Install Rail 3 Kit 1 x ProLiant DL3XX Gen11 Intrusion Cable Kit Power Cord
Memory
- Number of Occupied Memory Slots
- 2
- Total Number of Memory Slots
- 32
- Memory Technology
- DDR5 SDRAM
- Error Checking
- ECC
- Maximum Memory Supported
- 8 TB Byte
- Signal Processing
- Registered (Buffered)
- Standard Memory
- 64 GB Byte
Physical Characteristics
- Height
- 1.7" mm
- Width
- 17.1" mm
- Depth
- 29.7" mm
- Rack Height
- 1U
- Form Factor
- Rack
- Weight (Approximate)
- 43.96 lb g
Interfaces/Ports
- VGA
- Yes
- Number of Network (RJ-45) Ports
- 4
- Network (RJ-45)
- Yes
- Remote Management
- Yes
- Total Number of USB Ports
- 5
- Remote Management Controller
- Included - HPE iLO7 Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download). Optional - HPE iLO7 Advanced, HPE OneView Advanced, HPE Compute Ops Management (optional subscription available)
Display & Graphics
- Graphics Memory Capacity
- 16 MB Byte
General Information
- Product Type
- Server
- Product Series
- DL360 Gen12
Storage
- Solid State Drive Interface
- Serial ATA/600
- Total Solid State Drive Capacity
- 1.88 TB Byte
- Number of Solid State Drives
- 2
