Representative imageJuniper SRX4600 High Availability Firewall
Juniper SRX4600 High Availability Firewall - Intrusion Prevention - Gigabit Ethernet, 10 Gigabit Ethernet, 40 Gigabit Ethernet, 100 Gigabit Ethernet - 400 Gbit/s Firewall Throughput - 3DES-CBC, AEC-CBC, AES-GCM, DES-CBC, SSL, MD5, SHA-1, SHA-128, SHA-384, SHA-256 - 7500 VPN - 28 Total Expansion Slots - 3 Year - 1U - Rack-mountable - TAA Compliant
● Ships on backorderFree US shipping3-day delivery30-day returns
Advertised price · GPC-payable · TAA-compliant configurations available.
Free download
Documents
- Product Type
- High Availability Firewall
- Ethernet Technology
- Gigabit Ethernet
- Ethernet Technology
- 10 Gigabit Ethernet
- Ethernet Technology
- 40 Gigabit Ethernet
- Ethernet Technology
- 100 Gigabit Ethernet
- Product Family
- SRX
- TAA Compliant
- Yes
- Data Link Protocols
- HTTP
Overview
Juniper SRX4600 High Availability Firewall - Intrusion Prevention - Gigabit Ethernet, 10 Gigabit Ethernet, 40 Gigabit Ethernet, 100 Gigabit Ethernet - 400 Gbit/s Firewall Throughput - 3DES-CBC, AEC-CBC, AES-GCM, DES-CBC, SSL, MD5, SHA-1, SHA-128, SHA-384, SHA-256 - 7500 VPN - 28 Total Expansion Slots - 3 Year - 1U - Rack-mountable - TAA Compliant (part number B-SRX4600AC-DCTP3T) is supplied by Uniqcli, an authorized HPE & Juniper partner, in the Juniper Network Security & Firewalls category. Manageable: Yes.
The SRX4600 Firewall protects mission-critical data center and campus networks for enterprises, mobile service providers, and cloud service providers. Designed for highperformance security services architectures, the SRX4600 protects critical corporate IT assets as a next-generation firewall (NGFW), acts as an enforcement point for cloud-based security solutions, and provides application visibility and control to improve the user and application experience. Integrating networking and security in a single platform, the SRX4600 features multiple high-speed interfaces, intrusion prevention, advanced threat protection, and authentication, along with high-performance IPsec VPN and Internet gateway capabilities. It also offers high scalability, high availability, robust protection, application visibility, user identification, and deep content inspection to provide unparalleled control over the security infrastructure. The SRX4600 also acts as a central enforcement point, leveraging vital automation and actionable intelligence to protect users in a multivendor network environment. The SRX4600 also delivers fully automated SD-WAN to both enterprises and service providers. Due to its high performance and scale, the SRX4600 acts as a VPN hub and terminates VPN/secure overlay connections in various SD-WAN topologies. The SRX4600 is powered by Juniper Networks Junos® operating system, the industryleading OS that keeps the world's largest mission-critical enterprise and service provider networks secure. Architecture and Key Components The SRX4600 hardware and software architecture provides cost-effective security in a small 1 U form factor. Purpose-built to protect network environments and provide Internet Mix (IMIX) firewall throughput up to 400 Gbps, the SRX4600 incorporates multiple security services and networking functions on top of Junos OS. Best-in-class security and advanced threat mitigation capabilities on the SRX4600 are offered as 33 Gbps of NGFW, 45.4 Gbps of intrusion prevention system (IPS), and up to 44 Gbps of IPsec VPN in data center, enterprise campus, and regional headquarter deployments with IMIX traffic patterns.
• Offers reliable firewall synchronization to prevent a single point of failure on your network with maximum productivity • Proven firewall appliance with threat protection firewall protection support provides secure data transfer on your network • 3DES-CBC encryption standard for reliable protection of your precious and valuable data from unauthorized access • Gigabit Ethernet port for ultra-fast network speeds • Rack mounting enables you to organize wires & secure cables for professional installation
Key specifications: Manageable: Yes · Compatible Rack Unit: 1U · Height: 1.7" mm · Width: 17.4" mm · Depth: 27.3" mm · Form Factor: Rack-mountable · Weight (Approximate): 38 lb g · Encryption Standard: 3DES-CBC, AEC-CBC, AES-GCM, DES-CBC, SSL, MD5, SHA-1, SHA-128, SHA-384, SHA-256.
GPC-payable, with SAP, FAR-based purchase orders, and GSA eBuy support. Ask us about TAA-compliant configurations, current pricing, stock, and lead time.
Tech specs
Management & Protocols
- Manageable
- Yes
Physical Characteristics
- Compatible Rack Unit
- 1U
- Height
- 1.7" mm
- Width
- 17.4" mm
- Depth
- 27.3" mm
- Form Factor
- Rack-mountable
- Weight (Approximate)
- 38 lb g
Technical Information
- Encryption Standard
- 3DES-CBC, AEC-CBC, AES-GCM, DES-CBC, SSL, MD5, SHA-1, SHA-128, SHA-384, SHA-256
- Firewall Throughput
- 400 Gbit/s Bps
- Functionality
- Intrusion Prevention
- Number of VPN Supported
- 7500
- Data Link Protocols
- HTTP
- Number of Concurrent Sessions (Max)
- 60000000
- New Connections Per Second
- 600000
- Connectivity Technology
- Wired
- Firewall Protection Supported
- Threat Protection, Threat Intelligence, Application Control, SaaS Security, Antivirus, Anti-spam, Integrated Web Filtering, Malware Protection, DNS Security, Zero-day Threat Prevention, Remote Access Authentication, Distributed Denial of Service (DDoS), Traffic Anomaly Detection, SSL Inspection, Dead Peer Detection, Intrusion Prevention, URL Filtering, Botnet Detection, SSL Decryption, Access Control, Web Content Filtering, Advanced Threat Protection
I/O Expansions
- Number of SFP+ Slots
- 24
- Total Number of Expansion Slots
- 28
- Expansion Slot Type
- SFP+, QSFP28
Miscellaneous
- TAA Compliant
- Yes
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS) 2
- Package Contents
- SRX4600 High Availability Firewall 2 x AC Power Supply Unit 5 x Fan Trays Cables Rack Mount Kit
Media & Performance
- VPN Throughput
- 8.70 GB/s Bps
- IPS Throughput
- 5.69 GB/s Bps
Interfaces/Ports
- USB
- Yes
Warranty
- Support/Service Duration
- 3 Year Second
Power Description
- Power Consumption
- 650 W W
Network & Communication
- Ethernet Technology
- Gigabit Ethernet, 10 Gigabit Ethernet, 40 Gigabit Ethernet, 100 Gigabit Ethernet
General Information
- Product Type
- High Availability Firewall
- Product Series
- SRX
- Product Model
- SRX4600
